1SBN019010R1001

The ABB CA5X-01 Auxiliary Contact Block is a compact, front-mounted accessory designed to add an auxiliary contact function to compatible ABB contactors. Identified by product code 1SBN019010R1001, this one-pole block provides one normally closed (1 NC) instantaneous contact. It is suitable for ABB AX06–AX150 contactors and NX contactor relays, making it a practical choice for compatible industrial control-panel and motor-control applications.

The auxiliary contact can be incorporated into control circuits for status signaling, feedback, and interlocking, according to the application’s circuit design. Screw terminals provide the connection points for wiring. ABB lists a rated insulation voltage of 690 V and a conventional free-air thermal current of 16 A at 40°C. The maximum electrical switching frequencies are 1,200 cycles per hour for AC-15 and 900 cycles per hour for DC-13; the maximum mechanical switching frequency is 3,600 cycles per hour.

Choose the CA5X-01 when your installation requires a compatible ABB auxiliary contact block with a single NC contact. Contact Ahmedabad Electrical Corporation for product details and availability.
