1SBN019040R1022

The ABB CA5X-22E Auxiliary Contact Block is a four-pole, front-mounted accessory designed for compatible ABB AX contactors. Identified by product code 1SBN019040R1022, it provides two normally open (2 NO) and two normally closed (2 NC) instantaneous auxiliary contacts. These additional contacts can be incorporated into suitable control circuits for contactor status indication, feedback, and interlocking.

The CA5X-22E uses screw terminals and is intended for standard industrial environments, including control panels and motor-control assemblies. ABB lists a rated insulation voltage of 690 V, a conventional free-air thermal current of 16 A at 40°C, and a maximum electrical switching frequency of 1,200 cycles per hour for AC-15. The maximum mechanical switching frequency is 3,600 cycles per hour. For AC-15 operation, the listed rated current is 4 A at 220/240 V.

Choose this ABB auxiliary contact block when your application requires a 2 NO + 2 NC contact arrangement and compatibility with the relevant AX contactor. Contact Ahmedabad Electric Corporation for product details and availability.
