1SFA896104R7000

ABB PSR6-600-70 Softstarter, 3 kW, 6.8 A

The ABB PSR6-600-70 is a softstarter designed to provide controlled starting and stopping for compatible motors. Its soft-start and soft-stop functions support smoother operation, while the built-in bypass helps improve efficiency once the motor reaches operating speed. It is rated for 3 kW (4 HP) output and 6.8 A, with an operational voltage range of 208–600 V AC.

The control supply is 100–240 V AC at 50/60 Hz, and the specified ambient temperature range is −25°C to +60°C. Integrated motor protection is not available, so suitable external protection is required; the listing recommends an MS116 in the 4–10 A range. Optional FieldBusPlug communication is also listed.

Ahmedabad Electric Corporation can help you check availability and confirm whether the ABB PSR6-600-70 suits your motor and control-panel requirements.

Key specifications: ABB | PSR6-600-70 | 3 kW / 4 HP | 6.8 A | 208–600 V AC operational voltage | 100–240 V AC control supply | Soft start and soft stop | Built-in bypass
