1SFA896108R7000
Description
ABB PSR25-600-70 Softstarter, 11 kW, 25 A
The ABB PSR25-600-70 is designed to provide controlled starting and stopping for compatible motors. Its soft-start and soft-stop functions support smoother motor operation, while the built-in bypass helps improve efficiency after start-up. It is rated for 11 kW (15 HP) output and 25 A, with an operational voltage range of 208–600 V AC.
The control supply is 100–240 V AC at 50/60 Hz, and the specified ambient temperature range is −25°C to +60°C. Integrated motor protection is not available, so suitable external protection is required; the listing recommends an MS132 in the 20–25 A range. Optional FieldBusPlug communication is also listed.
Ahmedabad Electric Corporation can help you check availability and confirm whether the ABB PSR25-600-70 suits your motor and control-panel requirements.
Key specifications: ABB | PSR25-600-70 | 11 kW / 15 HP | 25 A | 208–600 V AC operational voltage | 100–240 V AC control supply | Soft start and soft stop | Built-in bypass
Specifications
| Rated soft starter current at Pe: Ie(A) | 25 ampere |
|---|---|
| Rated control supply voltage (Us) | 100 ... 240 volt AC |
