1SFL431024R8100

The ABB UA95-30-00RA 24 V, 50 Hz capacitor duty contactor is intended for switching three-phase capacitor banks in power factor correction applications. It can be used in electrical panels and installations where capacitor banks are controlled to help improve the power factor of the connected system.

This model has a 24 V AC control coil at 50 Hz and three normally open main contacts. ABB lists its rated capacitor-switching capacity as 60 kVAr at 400/415 V at 55°C and 70 kVAr at 400/415 V at 40°C. The manufacturer also specifies that the contactor can handle peak current up to 100 times the nominal RMS current during capacitor switching. shop.in.abb.com

The UA95-30-00RA belongs to ABB’s capacitor duty contactor range. Its application should be selected according to the capacitor-bank rating, system voltage, switching conditions and panel design. Check that the control supply matches the 24 V AC, 50 Hz coil specification, and verify compatibility with the installation’s protection and other components before ordering.
