1SFL431024R8600

The ABB UA95-30-00RA 400–415 V, 50 Hz capacitor duty contactor is designed for switching three-phase capacitor banks used in power factor correction systems. It can be integrated into suitable electrical panels to control capacitor-bank operation in commercial and industrial installations.

This model has a 400–415 V AC control coil at 50 Hz—rated 415–440 V at 60 Hz—and three normally open main contacts. ABB specifies its capacitor-switching capacity as 70 kVAr at 400/415 V at 40°C, 60 kVAr at 400/415 V at 55°C, and 53 kVAr at 400/415 V at 70°C. The manufacturer also specifies a permissible peak current of up to 100 times the nominal RMS current during capacitor switching. ABB eMart

Part of ABB’s capacitor duty contactor range, the UA95-30-00RA is intended for applications where its switching duty and control supply match the system requirements. Before installation, verify the control voltage, capacitor-bank rating, ambient conditions, protection arrangement and panel compatibility.
