1SFL471001R8611

ABB A145-30-11 Contactor — 400–415 V AC Coil

The ABB A145-30-11 is a three-pole block contactor designed for switching and controlling three-phase motors and other industrial electrical loads. Its coil operates at 400–415 V AC, 50 Hz, or 415–440 V AC, 60 Hz. It includes three main normally open contacts, plus one normally open and one normally closed auxiliary contact for control and signalling.

At 55°C, the contactor has an AC-3 operational current rating of 145 A from 220 V to 500 V and 120 A at 690 V. Its listed motor power ratings include 75 kW at 380–415 V and 110 kW at 690 V. Suitable applications include motor starting, isolation, bypass and distribution, subject to correct selection for the system’s operating conditions. Contact Ahmedabad Electrical Corporation for product enquiries.

Product code: 1SFL471001R8611

Extended type: A145-30-11-86
