1SFL491001R8011

ABB A185-30-11 Contactor — 220–230 V AC Coil

The ABB A185-30-11 is a three-pole block contactor for switching and controlling three-phase motors and other industrial electrical loads. Its coil operates at 220–230 V AC, 50 Hz, or 230–240 V AC, 60 Hz. It has three main normally open contacts, along with one normally open and one normally closed auxiliary contact for control and signalling circuits.

At 55°C, the AC-3 operational current rating is 185 A from 220 V to 440 V and 170 A at 500–690 V. Its listed motor power ratings include 55 kW at 220–240 V, 90 kW at 380–440 V, and 132 kW at 690 V. The contactor is suitable for motor starting, isolation, bypass and distribution applications when selected according to the system requirements. Contact Ahmedabad Electrical Corporation for product enquiries.

Product code: 1SFL491001R8011

Extended type: A185-30-11-80
