1SFL491001R8111

ABB A185-30-11 Contactor — 24 V AC Coil

The ABB A185-30-11 is a three-pole block contactor designed for switching and controlling three-phase motors and other industrial electrical loads. Its coil operates at 24 V AC at both 50 Hz and 60 Hz. The contactor has three main normally open contacts, plus one normally open and one normally closed auxiliary contact for control and signalling circuits.

At 55°C, its AC-3 operational current rating is 185 A from 220 V to 440 V and 170 A at 500–690 V. Listed motor power ratings include 55 kW at 220–240 V, 90 kW at 380–440 V, 110 kW at 500 V, and 132 kW at 690 V. Suitable applications include motor starting, isolation, bypass and distribution, subject to correct selection for the operating conditions. Contact Ahmedabad Electrical Corporation for product enquiries.

Product code: 1SFL491001R8111

Extended type: A185-30-11-81
