1SFL491001R8411

ABB A185-30-11 Contactor — 110 V AC Coil

The ABB A185-30-11 is a three-pole block contactor designed for switching and controlling three-phase motors and other industrial electrical loads. Its coil operates at 110 V AC, 50 Hz, or 110–120 V AC, 60 Hz. It features three main normally open contacts, plus one normally open and one normally closed auxiliary contact for control and signalling circuits.

At 55°C, its AC-3 operational current rating is 185 A from 220 V to 440 V and 170 A at 500–690 V. Listed motor power ratings include 55 kW at 220–240 V, 90 kW at 380–440 V, and 132 kW at 690 V. This contactor is suitable for motor starting, isolation, bypass and distribution applications when selected according to the system’s operating requirements. Contact Ahmedabad Electrical Corporation for product enquiries.

Product code: 1SFL491001R8411

Extended type: A185-30-11-84
