1SFL491001R8611

ABB A185-30-11 Contactor — 400–415 V AC Coil

The ABB A185-30-11 is a three-pole block contactor designed for switching and controlling three-phase motors and other industrial electrical loads. Its coil operates at 400–415 V AC, 50 Hz, or 415–440 V AC, 60 Hz. It has three main normally open contacts, plus one normally open and one normally closed auxiliary contact for control and signalling circuits.

At 55°C, the AC-3 operational current rating is 185 A from 220 V to 440 V and 170 A at 500–690 V. Its listed motor power ratings include 90 kW at 380–440 V, 110 kW at 500 V and 132 kW at 690 V. It is suitable for motor starting, isolation, bypass and distribution applications when selected for the system’s operating conditions. Contact Ahmedabad Electrical Corporation for product enquiries.

Product code: 1SFL491001R8611

Extended type: A185-30-11-86
