1SFL981074R8011

The ABB AX115-30-11-80 is a robust 3-pole block contactor designed for dependable switching and control of industrial AC loads and motors. It features 3 normally open main contacts, 1 normally open and 1 normally closed auxiliary contact, a 1000 V rated main circuit, and a 160 A conventional free-air thermal current at 40°C.

For AC-3 applications, it supports up to 115 A at 415 V and delivers up to 59 kW. The contactor is equipped with a 220–230 V AC coil at 50 Hz and 230–240 V AC at 60 Hz. It offers 690 V insulation voltage, 8 kV impulse withstand voltage, 10 million mechanical operations, and a maximum mechanical switching frequency of 3,600 cycles per hour.

With main circuit bar terminals and reliable ABB construction, the AX115-30-11-80 is suitable for motor control panels, automation systems, pumps, compressors, HVAC equipment, and other demanding industrial applications.
