1SBL411074R8611

**ABB AX80-30-11-86 400–415V AC Contactor – 80A, 3 Pole, 40 kW**

ABB AX80-30-11-86 is a reliable 3-pole AC contactor designed for switching and controlling three-phase motors and industrial power circuits. It operates with a 400–415V AC control coil at 50 Hz and a 415–440V AC coil supply at 60 Hz, making it suitable for industrial motor-control and automation applications.

The contactor is equipped with 3 normally open main contacts and 1 normally open plus 1 normally closed auxiliary contact for interlocking, indication, feedback and control circuits. Both the main and auxiliary circuits are rated up to 690V AC, while the rated frequency is 50/60 Hz.

For motor applications, ABB AX80-30-11-86 provides an AC-3 operational current rating of up to 80A at 380/400/415V AC and supports motor power up to 40 kW at 415V. Its AC-3 ratings include 70A at 440V, 65A at 500V and 46A at 690V. The conventional free-air thermal current is 125A at 40°C.

The block-type AX80 construction allows optional side-mounted auxiliary contact blocks and a wide range of compatible ABB accessories. It is suitable for MCC panels, pump and compressor panels, HVAC systems, OEM machinery, industrial automation panels, motor starters and power-control applications.

Product details: Extended Product Type: AX80-30-11-86; ABB Product ID: 1SBL411074R8611; EAN: 3471522408860; Configuration: 3P, 3NO main contacts, 1NO + 1NC auxiliary contacts; AC-3 rating: 80A at 415V; Motor power: 40 kW at 415V.

Ahmedabad Electrical Corporation can assist with genuine ABB contactors, technical selection and industrial switchgear supply.
